Place of Origin: | China |
Brand Name: | Shuowei |
Certification: | CE SGS ISO9001 |
Model Number: | R series |
Minimum Order Quantity: | 1PCS |
---|---|
Price: | Negotiable |
Packaging Details: | Wooden Case; Customized Packing Is Acceptable |
Delivery Time: | 5-8 Work Days |
Payment Terms: | L/C, T/T |
Supply Ability: | 100 Piece Per Month |
Customized Support: | OEM | Output Torque: | 800~100000N.m |
---|---|---|---|
Output Speed: | 14-280rpm | Type: | Hydraulic Motor Reducer |
Power: | Hydraulic | Input Speed: | 1400rpm |
High Light: | 100000N.M Worm Gear Rack,100000N.M 14rpm Worm Gear Rack,280rpm Helical Gear Units |
Helical Gear Units Small Transmission Gearbox Bevel Helical Gearbox Screw Jack
Gear Reducer Jack Parameters:
Type | Model | Screw thread size |
Max lifting strength kN |
Max pull force kN |
Weight without stroke kg |
Screw weight per 100mm |
SWL
Screw jack
|
SWL2.5 | Tr30*6 | 25 | 25 | 7.3 | 0.45 |
SWL5 | Tr40*7 | 50 | 50 | 16.2 | 0.82 | |
SWL10/15 | Tr58*12 | 100/150 | 99 | 25 | 1.67 | |
SWL20 | Tr65*12 | 200 | 166 | 36 | 2.15 | |
SWL25 | Tr90*16 | 250 | 250 | 70.5 | 4.15 | |
SWL35 | Tr100*18 | 350 | 350 | 87 | 5.20 | |
SWL50 | Tr120*20 | 500 | 500 | 420 | 7.45 | |
SWL100 | Tr160*23 | 1000 | 1000 | 1010 | 13.6 | |
SWL120 | Tr180*25 | 1200 | 1200 | 1350 | 17.3 |
1. High quality, It adopts hard tooth gear with high accuracy
2. Large output torque, stable transmission with lower noise
3. High heat-radiating efficiency, elegant shape, durable service life
Application Industries:
Our screw jacks are widely used in the industries such as metallurgy,mining,hoisting and transportation, electrical power,energy source,constrction and building material,light industry and traffice industry
FAQ:
Q1. How can I choose the model that best meets my requirements?
A1. You can refer to our catalog to choose the gearbox or we can help to choose when you provide the technical information of required output torque, output speed and motor parameters, etc.
Q2. What information shall we give before placing a purchase order?
A2. a) Type of the gearbox, ratio, input and output type, input flange, mounting position, and motor detail, etc.
b) Housing color.
c) Purchase quantity.
d) Other special requirements.
Q3. What industries are your gearboxes being used in?
A3. Our gearboxes are widely used in automatic machinery and equipment in textile, food processing, beverage, chemical industry, escalator, automatic storage equipment, metallurgy, tobacco, environmental protection, logistics and other fields.
